PVDC Coated BOPP Film

SD-B1P0 PVDC Coated BOPP Film layer structure schematic

Layer structure and packaging application illustrations; schematic, not to scale. Colors do not represent actual film colors. View full-size structure ↗

SD-B1P0

Product summary

SD-B1P0 is an SD PACK PVDC Coated BOPP Film on a BOPP substrate. Typical application: high-barrier lamination and bag making.

Substrate
BOPP
Coating
PVDC
Structure
One side
Inquire about SD-B1P0 ↗

Technical data is available below. Include your target specifications when requesting samples.

01 / PRODUCT OVERVIEW

Meet SD-B1P0.

Discuss your packaging format and converting process with our team to confirm the right film for your project.

02 / PRODUCT SPECIFICATIONS

Product at a glance.

Product identification — SD-B1P0
Product codeSD-B1P0
Product familyPVDC Coated Films
Base substrateBOPP
Coating materialPVDC
Coated sides / structureOne side
Typical applicationsHigh-barrier lamination and bag making.
TECHNICAL DATA SHEET

Typical physical properties

TDS available

SI values transcribed from the supplied SD-B1P0 TDS. Columns correspond to the listed film thicknesses.

PVDC Coated BOPP Film — SD-B1P0
Property / conditionUnitTest method / condition21 µm30 µm
ThicknessµmSD Test2130
Yieldm²/kgSD Test50.7634.72
Unit weightg/m²SD Test19.628.8
Haze%ASTM D10031.21.2
Tensile strength (MD)MPaASTM D882155155
Tensile strength (TD)MPaASTM D882290290
Elongation at break (MD)%ASTM D882150150
Elongation at break (TD)%ASTM D8825050
Surface tension (PVDC side)dyn/cmASTM D25784242
WVTR (38°C, 90% RH)g/(m²·24 h)ASTM F12494.54.5
OTR (23°C, 0% RH)cm³/(m²·24 h)ASTM D39859.09.0
C.O.F. (PVDC/PVDC)DimensionlessASTM D18940.40.4
Heat resistance (MD)%ASTM D1204; 120°C, 2 min1.51.5
Heat resistance (TD)%ASTM D1204; 120°C, 2 min1.01.0
Seal StrengthN/15 mmASTM F88; 135°C, 0.25 MPa, 0.5 s1.01.0
Typical values, not guaranteed specifications. Confirm product compatibility and agreed purchase specifications with SD PACK before use. A dash or “/” in the source means no value is stated; it is not zero.
03 / TYPICAL APPLICATIONS

Where it fits.

High-barrier lamination and bag making.

Applications are summarized from the supplied product literature. Confirm suitability for your packed product, processing conditions and destination-market requirements before ordering.

04 / CONTACT OUR TEAM

Let’s discuss SD-B1P0.

Tell us what you need. Our sales team can discuss the available specifications and sample requirements.

Request a film recommendation

Your inquiry will be sent to our sales team and stored for follow-up. Privacy information

Before you order.

Can I download a technical data sheet?

Yes. Use the TDS download button in the Specifications section. Contact our team to confirm current specifications, availability and test conditions.

How do I request a quote or sample?

Send your application, thickness, width, quantity and destination. Sample availability, minimum order quantity, lead time and commercial terms will be confirmed by the sales team.
