Layer structure and packaging application illustrations; schematic, not to scale. Colors do not represent actual film colors. View full-size structure ↗
Two-side Acrylic Coated BOPP Film
SD-B2P2 is a double-sided acrylic coated BOPP film with acrylic coating on both sides of a biaxially oriented polypropylene substrate. It is offered for aroma-protection packaging, including cosmetic box overwrap. Review the technical data and confirm printing, sealing and converting conditions for your application.
- Substrate
- BOPP
- Coating
- Acrylic
- Structure
- Two sides
Technical data is available below. Include your target specifications when requesting samples.
Acrylic coating on both sides of BOPP film.
Discuss your packaging format and converting process with our team to confirm the right film for your project.
Product at a glance.
| Product code | SD-B2P2 |
|---|---|
| Product family | Acrylic Coated Films |
| Base substrate | BOPP |
| Coating material | Acrylic |
| Coated sides / structure | Two sides |
| Typical applications | Aroma-protection packaging, including cosmetic boxes. |
Typical physical properties
SI values transcribed from the supplied SD-B2P2 TDS. Columns correspond to the listed film thicknesses.
| Property / condition | Unit | Test method / condition | 30 µm | 35 µm | 40 µm |
|---|---|---|---|---|---|
| Thickness | µm | SD Test | 30 | 35 | 40 |
| Yield | m²/kg | SD Test | 36.47 | 31.26 | 27.36 |
| Unit weight | g/m² | SD Test | 27.42 | 31.99 | 36.55 |
| Haze | % | ASTM D1003 | 1.7 | 1.7 | 1.7 |
| Gloss (45°) | % | ASTM D2457 | 90 | 90 | 90 |
| Tensile strength (MD) | MPa | ASTM D882 | 150 | 150 | 150 |
| Tensile strength (TD) | MPa | ASTM D882 | 230 | 235 | 235 |
| Elongation at break (MD) | % | ASTM D882 | 160 | 160 | 160 |
| Elongation at break (TD) | % | ASTM D882 | 55 | 58 | 58 |
| Surface tension | dyn/cm | ASTM D2578 | 42 | 42 | 42 |
| WVTR (38°C, 90% RH) | g/(m²·24 h) | ASTM F1249 | 5.0 | 4.5 | 4.0 |
| OTR (23°C, 0% RH) | cm³/(m²·24 h) | ASTM D3985 | 1000 | 900 | 800 |
| Coefficient of friction | Dimensionless | ASTM D1894 | 0.25 | 0.25 | 0.25 |
| Seal Strength | N/15 mm | ASTM F88; 130°C, 0.18 MPa, 1 s | 2.5 | 3.0 | 3.5 |
Where it fits.
Aroma-protection packaging, including cosmetic boxes.
Applications are summarized from the supplied product literature. Confirm suitability for your packed product, processing conditions and destination-market requirements before ordering.
Let’s discuss SD-B2P2.
Request a double-sided acrylic coated BOPP film sample or quotation. Include your packaging application, thickness, roll width, printing and sealing process, quantity and delivery country in Europe or the Americas. Our team will confirm specifications and supply terms.
Before you order.
Can I download a technical data sheet?
Yes. Use the TDS download button in the Specifications section. Contact our team to confirm current specifications, availability and test conditions.
How do I request a quote or sample?
Send your application, thickness, width, quantity and destination. Sample availability, minimum order quantity, lead time and commercial terms will be confirmed by the sales team.
